Name: Outdoor Digital Wireless Ethernet Bridge OFDM Modulation 58GHz 8km
Brand: SUNTOR
Price: 1 USD

Brand Name : SUNTOR

Model Number : ST58T8G

Certification : FCC, CE, RoHS

Place of Origin : Shenzhen, China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 set/ month

Delivery Time : 7-15 days

Packaging Details : Plastic Box

Modulation : OFDM

Frequency : 5150-5825MHz

Transmit Power : 29±2dBm

Wireless Mode : PTP and PTMP

Support Range : 5-8km(LOS)

Operation temperature : -30°C~ +70°C

Function : Audio video and network signal

Contact Now

5.8GHz 5-8km outdoor digital wireless ethernet bridge

Model	ST58T8G
Standards Compliance	IEEE 802.11a/n; IEEE802.3; IEEE802.3u
CPE Processor	Atheros AR7240+AR9280
SDRAM	32 M Byte
Flash	8 M Byte
Radio Frequency Type	OFDM
Modulation	IEEE 802.11a: OFDM with BPSK, QPSK, 16QAM, 64QAM
Frequency Band	5.15 ~ 5.25 GHz (lower band) 5.25 ~ 5.35 GHz (middle band) 5.725 ~ 5.825 GHz (hi-band)
Transmission Power	29±2dBm
Transmission Rate	IEEE 802.11a: 6/9/12/18/24/36/48/54/108 Mbps
Access Point Interfaces	Auto sensing MDI/MDI-X Ethernet 10/100Base-T x 2: RJ-45
Sensitivity	IEEE 802.11a:-94dBm @ 6Mbps; -74dBm @ 54Mbps, PER<10%
Antenna Type	Integrated 18dBi dual-polarized directional antenna
Security Systems	64-bit/128-bit/152-bit WEP encryption; WPA/ WPA2 (-PSK or -EAP with TKIP/AES encryption); 802.1x Authenticator, EAP-PEAP/EAP-TTLS support for client mode; Hide SSID in beacons
Wireless Setting	Operation Mode – AP/ Client Bridge/ WDS Bridge PtP and PtMP (up to 16 links)/ Client Router Auto/Fixed Channel Selection (Setting varies by Country) Adjustable transmit power by 1dBm step
Operating Temperature	-30 ~ +70°C
Power	Passive PoE DC18 Volt + 5%; 20Watt (Max.); AC adapter AC 100V ~ 240V
Network Management System OS Support	Windows 2000/XP/Vista Home Basic/Windows 7
Warranty	One year limited

Built-in 18dBi panel antenna, more convenient in installing.
High Transmission Power up to 29dBm and Extended excellent Range and Coverage(fewer APs)
High Speed Data Rate Up to 300Mbps 2T2R, the transmission signal is strong and stable.
Built-in Software Detects Surrounding Frequency Interference, use the best channel to transmit stable
Simultaneously as a wireless repeater up to 8 links
Multifunction application Access Point/WDS Bridge/Client Bridge + Repeater mode

Outdoor Digital Wireless Ethernet Bridge OFDM Modulation 5.8GHz 8km
